Trace optical specializes in the design, development, production and sales of various optical lenses .The factory is located in Shenzhen, and Jiangxi, and currently has more than 500 employees
Structure: 4G + 2P, aperture: 2.00, TTL: 14.8mm
0.98 Large aperture for Aurora night vision
Cost-effective :2G + 4P, F1.40, TTL: 22.3mm
zero distortion:1G + 4P, F 2.4, TTL:15.75mm
Structure：2G + 4P, aperture: 2.00, TTL: 12.0mm
TRC-2117A6-01 (Car DVR) structure: 2G+4P, aperture: 1.40, TTL: 22.3mm
Highlights: a. High cost performance b. High and low temperature correction beyond all-glass lenses c. Complete elimination of purple fringing and chromatic aberration d.
Surpassing the large aperture of 6G products of the same level
Structure: 2G+4P, Aperture: 2.20, TTL: 17.0mm
Highlights: a. High cost performance b. With OV2312 HFOV126°c. -40 to 85 degrees high and low temperature correction d. Good confocal infrared 940nm
TRC-2308D26-01 (CR DVR) structure: 2G+5P, aperture: 1.75, TL: 22.3mm
Highlights: High cost performance B. Real 4K picture quality can be achieved with IMX415 c. Purple fringing correction
TRC-20219C6 (Car-360) structure: 2G+5P, aperture: 1.80 TTL: 16.9mm
Highlights: a. Cooperate with IMX021&031; to achieve high-definition surround view b. -40 to 95 degrees high and low temperature correction
c. Purple fringing correction
TRC-20805A26 (Video & Recognition & Scanning) Structure: 2G+4P, TTL: 20.7mm
Highlights: a. Non-distortion (H viewing angle 110 degrees) b. 4K picture quality, matching IMX415
